Manufactured by CHG Bearing, the 510/800 is a precision Tapered Roller Thrust Bearings. Key dimensional parameters include a 800 mm bore diameter, a 870 mm outer diameter, and a mm overall width. This component is designed to meet standard load requirements and ensure consistent operational performance. For comprehensive technical evaluation, please explore the detailed specifications, dimensional data, product images, and CAD drawings provided below. A complete PDF data sheet is also readily available for direct download to support your engineering and procurement needs.
510/800 - Tapered Roller Thrust Bearings
Technical Specifications
| Overview | |
|---|---|
| Part Number | 510/800 |
| Brand | CHG® |
| Construction | Thrust Ball Bearing |
| Type | Single-Direction Thrust Ball Bearing |
| Characteristics | |
| Load Direction | Axial — Single Direction |
| Limiting Speed — Grease (r/min) | 430 r/min |
| Limiting Speed — Oil (r/min) | 560 r/min |
| Dimensions | |
| Bore Diameter (d) | 800 mm |
| Outer Diameter (D) | 870 mm |
| Contact Angle α (°) | N/A ° |
| Chamfer Dimension r (min.) | 1.5 mm |
| Dimension A | N/A mm |
| Bearing Height T | 53 mm |
| Dimension d1 | 802.5 mm |
| Dimension D12 | 867.5 mm |
| Dimension C | N/A mm |
| Dimension B | N/A mm |
| Chamfer Dimension r1 (min.) | N/A mm |
| Performance | |
| Basic Dynamic Axial Load Rating Ca (kN) | 334 kN |
| Basic Static Axial Load Rating C0a (kN) | 2880 kN |
| Material | |
| Mass (kg) | 32.5 kg |
510/800 870 mm 802.5 mm 800 mm 867.5 mm Frequently Asked Questions about 510/800 Tapered Roller Thrust Bearings
Find key technical answers regarding dimensions, specifications, and replacement options for this model.
Built for demanding industrial environments, the 510/800 Tapered Roller Thrust Bearings by CHG Bearing boasts a dynamic load rating (Cr) of standard dynamic and a static load threshold (C0r) of standard static. The optimized internal raceway geometry balances stress distribution, mitigating edge loading even when operating under peak mechanical stresses.
Yes, 100% of 510/800 Tapered Roller Thrust Bearings leaving CHG Bearing production lines are subjected to multi-frequency Anderometer sound testing. All units satisfy baseline Z1V1 levels, with dedicated quiet-running electric motor quality (EMQ) lots certified to Z2V2 and Z3V3 standards for silent machinery integration.
Model 510/800 is manufactured by CHG Bearing in standard Normal clearance (CN) for ambient temperature transmission, and C3 or C4 clearance for heavy duty applications. C3 clearance compensates for radial shrinkage caused by tight shaft press-fits (bore 800 mm) and steep thermal gradients between inner and outer rings.
Each 510/800 produced in CHG Bearing manufacturing facilities features accurately profiled corner chamfers complying with DIN 5412 / ISO standard corner radii. When designing mating shafts and housing shoulders, machining an undercut or fillet radius strictly within the inner ring clearance limit (800 mm bore side) ensures perfect planar contact without edge binding.
